| Storage capacity |
Fingerprints templates |
3000 |
| |
Card Storage |
30000 |
| |
Transaction storage |
1,00,000 |
| |
Card reader |
Yes |
| |
CPU |
400 Mhz |
| Biometric |
Fingerprint sensor |
500 DPI Optical sensor |
| |
FAR |
<=0.0001% |
| |
FRR |
<=1% |
| |
Identification speed |
<=0.5sec |
| |
Algorithm Ver |
10 |
| Audio/Visual |
Display |
NA |
| |
Keypad |
NA |
| |
LED Indicator |
Green/Red |
| |
Schedule Bell/Speaker |
Mini Speaker |
| Communication |
Communication |
RS485 , TCP/IP , USB-host |
| |
Push data |
No |
| |
Standard features |
DLST |
| Power & Environment |
Power Supply |
12V DC, 1.5A |
| |
Operating Temperature |
-40°C - 45°C |
| |
Operating Humidity |
20% -80% |
| |
Dimension |
62.5 x 185 x 41.5mm |
| Access Control |
Wiegand |
In & Out both |
| |
Relay |
12 V relay for lock |
| |
Support Fire Alarm |
Yes |
| |
Door Sensor |
Yes |
| |
Anti Passback |
Yes |
| |
Door Bell |
Yes |
| Exit Readers |
Support exit readers |
KR500,101 HE |
| Optional |
Battery |
No |
| |
Card readers |
Yes |
| |
Communication |
No |
| |
Sensor |
EM Lock (Standard)Mifare (Optional) |
| Compatibility |
|
Compatible with Multi Door controllers via weigand |
| |
|
External Speaker output available (Optional) |
| |
|
External Bulb output available (Optional) |
| Compatible Software and SDK |
|
SDK for desktop applications |
| |
|
Supports 3rd Party Payroll/HRMS/ERP and Other applications |
| Major Applications |
|
Time & Attendance , Canteen management, School attedance, |
| |
|
Production Management, Gym & clubs |
