| Storage capacity |
Fingerprints templates |
3000 |
| |
Card Storage |
3000 |
| |
Transaction storage |
1,00,000 |
| |
Card reader |
Inbuilt proximity card reader( optional Mifare,HID prox) |
| |
CPU |
800 Mhz 32 bit Microprocessor |
| Biometric |
Fingerprint sensor |
500 DPI Optical sensor |
| |
FAR |
|
| |
FRR |
|
| |
Identification speed |
|
| |
Algorithm Ver |
10 |
| Audio/Visual |
Display |
3" Color TFT |
| |
Keypad |
Yes |
| |
LED Indicator |
Green/Red |
| |
Schedule Bell/Speaker |
Mini Speaker |
| Communication |
Communication |
TCP/IP, USB, ( Optional : Wifi, GPRS, GPRS+ GPS) |
| |
Push data |
yes (support both static IP and domain server) |
| |
Standard features |
work code,SMS,DLST, Self service query, Status Switch |
| Power & environment |
Power Supply |
DC 12V: 1.5Amp |
| |
Operating Temperature |
0oC to 45oC |
| |
Operating Humidity |
20% -80% |
| |
Dimension |
210x157x40 |
| Access control |
Wiegand |
In & Out both 26 or 34 bit (With or without site code) |
| |
Relay |
12 V relay for lock EM lock, Bolt Lock or Strike lock |
| |
Support Fire Alarm |
Yes |
| |
Door Sensor |
Yes |
| |
Anti Passback |
Yes |
| |
Door Bell |
Yes |
| Exit Readers |
Support exit readers |
101 HE , FR 1200, Push Button, KR500, Notouch, KR503 |
| Optional |
Battery |
yes |
| |
Card readers |
Mifare/HID Prox/HID Iclass |
| |
Communication |
Wifi/GPRS |
| |
Sensor |
Mifare/HID Prox/HID Iclass |
| Compatibility |
|
Compatible with Multi Door controllers via weigand |
| |
|
External Speaker output available (Optional) |
| |
|
External Bulb output available (Optional) |
| |
|
Support External Printer |
| Compatible Software and SDK |
|
Smart office suite desktop and web |
| |
|
etime track lite desktop & web |
| |
|
SDK for desktop applications |
| |
|
Web based Device Manager/ePush server using Push data. Helps developers & integrators |
| |
|
Supports 3rd Party Payroll/HRMS/ERP and Other applications |
| Major Applications |
|
Time & Attendance , Canteen management, School attedance, |
| |
|
Production Management, Gym & clubs |
