| Face capacity: |
500 |
| Card capacity: |
5000 |
| Fingerprint capacity: |
5000 |
| Max Attendance log: |
300,000 |
| Management log: |
10000 |
| Identify mode: |
Face, Fingerprint, card, password and combinations |
| Display language: |
English |
| LED: |
1 (Red-Green dual color) |
| Wiegand input: |
Inside and Output Wiegand(26/34) |
| Exit button input: |
Supported |
| Door sensor input: |
Supported |
| Bell relay: |
Supported |
| Door relay: |
Supported |
| Wiegand output: |
Supported |
| Tamper input: |
Supported |
| Communication: |
TCP-IP,WIFI(Optional) |
| U-disk: |
Supported |
| Audio output: |
Voice Interface |
| Battery: |
3 Hrs Battery Backup(Optional) |
| Working voltage: |
DC12V ± 5%(current : below 1.5A) |
| Working temperature: |
-10°c~ +60°c |
| Working humidity(RH): |
20% ~ 80% |
| Search attendance log: |
Support (After authentication, user can look his/her attendance logs.) |
| Door Control: |
Directly control of door lock/Indirectly control of door lock via wiegand Access Controller. |
| Power management: |
Sleep Mode |
| FAR/ FRR: |
0.001/1(%) |
| Identify speed: |
≤1.0 seconds |
| Intelligent adaptation function: |
Built-In |
| Matching mode: |
Supports 1:N |
| Fingerprint input angle: |
360°(any angle) |
| FAR/ FRR: |
0.00001/0.1(%) |
