| PRODUCT SPECIFICATIONS |
| Protocol : |
ISO18000-6B, ISO18000-6C (EPC GEN2) |
| Frequency Range : |
Standard ISM 902~928MHz or ISM 865~868MHz,other frequency available |
| Operation Mode : |
FHSS or fixed frequency(set by software) |
| RF Power : |
0~30dBm,software adjustable |
| Reading Speed: |
Software Programmable, Average Reading per 64Bits:<6ms |
| Reading Mode: |
Timing or Touch, Software Programmable |
| Data Ports : |
Standard: Wiegand26/34, RS485, RS232; Software Programmable Optional: WIFI, RJ45 |
| Data Input : |
Port Trigger input one team |
| Reading Range : |
Max 10M-15M |
| Reading Clue : |
Buzzer |
| Antenna : |
Built-in line polarization Antenna, Gain:12dbi |
| Power Supply : |
DC+12V (Power Adapter) |
| Dimension : |
440mm X 440mm X 50mm |
| Weight: |
4.5Kg |
| Operation Temperature : |
-20 C ~ +80 C |
